Chimeric Antigen Receptor T-cell (CAR-T) therapies are approved for the treatment of several haematological malignancies. However, their clinical success against the majority of solid tumour types has been limited thus far. The need for physiologically relevant, more complex in vitro models of cancer is steadily increasing due to the emergence of immunotherapeutic approaches such as cell therapies but also drugs that actively target the immune system within the tumour microenvironment (TME). Furthermore, an increasing interest in precision treatment of cancer patients and the rise of combination of anti-cancer therapies has highlighted a gap for 3D tumour models in efficacy tests. Miniaturization facilitates increased data generation, especially when using clinical samples.

To meet this growing demand, RoukenBio, the Immunology CRO redefined, has formed a strategic partnership with ScreenIn3D, bringing together RoukenBio’s expertise in immunology and bespoke assay development with ScreenIn3D’s cutting-edge 3D miniaturized microfluidic technology. This collaboration enables us to deliver advanced, physiologically relevant assays that accelerate and de-risk your drug discovery efforts.

Download the full research poster

Rethinking in vitro models: From 2D cultures to 3D cancer systems

As immunotherapies and drugs targeting the tumour microenvironment (TME) gain momentum, there is a growing need for in vitro cancer models that more accurately reflect human pathology. Traditional 2D cell cultures often fail to capture the complexity of cell–cell and cell–matrix interactions within the TME, limiting their predictive value in drug discovery and development.

To address this, we are turning to advanced 3D in vitro models that better replicate the structural and functional characteristics of solid tumours. These physiologically relevant systems enable more accurate assessment of immune cell infiltration, drug penetration, and tumour-immune cell dynamics which ultimately enhance the translational value of preclinical studies and accelerate the development of next-generation cancer therapies.

What are HER2-specific CAR-T cells?

HER2-specific CAR-T cells are genetically engineered T cells that express a chimeric antigen receptor (CAR) designed to recognise and kill cancer cells that overexpress HER2 (human epidermal growth factor receptor 2). HER2 is commonly overexpressed in several solid tumours, including breast, ovarian, gastric, and lung cancers, making it a valuable therapeutic target.

Why HER2 and what are the challenges?

Advantages of HER2 as a therapeutic target:

Overexpressed in many solid tumours
Correlates with aggressive disease
Established as a therapeutic target (e.g. trastuzumab, pertuzumab)

Challenges and Considerations:

On-target, off-tumour toxicity: HER2 is also expressed at low levels in healthy tissues (e.g. heart, lung), which can lead to severe adverse effects. Targeted therapeutics towards HER2 require careful selection to minimise targeting of philosophical (healthy) expression of HER2 on healthy tissues. Our HER2-inducible cell line via our IndEx-2 cell line platform was used to model expression levels and correlate with cytotoxicity.
Tumour heterogeneity: Variable HER2 expression can result in incomplete tumour clearance.
Immunosuppressive tumour microenvironment (TME): Solid tumours create barriers to CAR-T efficacy, including limited infiltration, inhibitory cytokines, and immune checkpoint signalling.

Generation of HER2-specific CAR-T cells for miniaturized 3D cancer models

Generation of HER2-specific CAR-T cells for miniaturized 3D cancer models

Second-generation CAR constructs targeting HER2 were designed incorporating CD3ζ (signal 1) and CD137/4-1BB (signal 2) domains. The high-affinity receptor was based on the trastuzumab-derived scFv (4D5), while the low-affinity variant (4D5-5) was generated using previously published mutations of 4D5¹.

Affinity-based differences on functionality were confirmed using a HER2 inducible IndEx-2 cell line that allows titratable expression of the target antigen.

Affinity-based differences on functionality were confirmed using a HER2 inducible IndEx-2 cell line that allows titratable expression of the target antigen.

UpScale^3D lab-on-a-chip technology

UpScale3D is a lab-on-a-chip technology developed by ScreenIn3D, our strategic partner. It focuses on miniaturizing and screening 3D disease models for drug discovery. The technology combines scalability with physiologically relevant microenvironments to assess molecule efficacy and improve candidate selection.

UpScale3D is a lab-on-a-chip technology developed by ScreenIn3D

Figure 1 Microfluidic plate with multiple device units

The advantages of using UpScale^3D

Long-term culture of perfused biopsy-derived and in vitro complex models
Unique miniaturization for combination studies
20X more data throughput for the same amount of starting material
50% faster to results

Long-term culture of perfused biopsy-derived and in vitro complex models

Figure 2 As low as 2,000 cells for tens of 3D cellular models per device

UpScale3D single, double and combi versions

High-throughput CAR-T cytotoxicity assays

High-throughput CAR-T cytotoxicity assays were used to measure how well CAR-T cells kill cancer cells.

High-throughput CAR-T cytotoxicity assays were used to measure how well CAR-T cells kill cancer cells.

Figure 5 Histograms of HER2 Induction at 0-50 μM ABA

HER2+ and HER2- expressing cancer cells were cultured in 3D within UpScale3D microfluidic platforms (ScreenIn3D).

Hundreds of spheroids were formed within 48 hours and, subsequently, CAR-Ts with low and high affinity for the target were co-cultured with the spheroids over 24-hour incubation at the desired E:T ratio.

CAR-Ts quickly targeted, disaggregated and specifically killed high HER2+ expressing cells in 3D models.

CAR-T cells elicited mild cytotoxicity in low/non-HER2+ expressing spheroids.

Figure 6 Histograms of HER2 Induction at 0-50 μM ABA

Figure 6 Histograms of HER2 Induction at 0-50 μM ABA

Miniaturized CAR-T efficacy assays for solid tumours using 3D spheroids and patient-derived models

In summary, we showed how high-throughput and miniaturized efficacy assays can demonstrate CAR-T mediated cytotoxicity using the HER2 receptor, a common target over-expressed in many types of solid tumours. Our versatile screening platform offers high quality and multiplexed assays to test therapy efficacy on spheroid co-cultures, organoids and primary tumour fragments. The platform offers a unique system to miniaturize drug combination studies using small quantities of cell samples, including tissue-derived 3D models of disease and, at the same time, provides cost-effective and fast immune-oncology assays for extensive drug combination studies and precision medicine drug discovery.

References:

1 Liu et al, CancerRes; 75(17) September 1,2015.

Special thanks to Karla Paterson, Ronan Mellin and Michele Zagnoni from ScreenIn3D who helped in the creation of our collaborative research poster presented at AACR.

Figures were created by using BioRender.
